SOLIDWORKS Flow Simulation Training

Prerequisite(s)

Some experience using SOLIDWORKS.

Length

2 Days

Available courses

Customer Testimonials

Description

Provides an in-depth session on the basics of turbulent fluid flow analysis, in addition to covering meshing concerns, modeling concerns, analysis, post-processing, available options and preferences.

Course outline

  • Case Study: Manifold Assembly
  • Model Preparation
  • Manifold Analysis
  • Exclude Cavities Without Flow Conditions
  • Computational Domain
  • Goal Plot Window
  • Post-processing
  • Exercise l: Air Conditioning Ducting
  • Case Study: Chemistry Hood
  • Computational Mesh
  • Basic Mesh
  • Initial Mesh
  • Geometry Resolution
  • Result Resolution/Level of Initial Mesh
  • Exercise 2: Square Ducting
  • Exercise 3: Thin Walled Box
  • Exercise 4: Heat Sink
  • Exercise 5: Meshing Valve Assembly
  • Case Study: Electronics Enclosure
  • Fans
  • Perforated Plates
  • Exercise 6: Materials with Orthotropic Thermal Conductivity
  • Exercise 7: Electric Wire
  • Case Study: Flow Around a Cylinder
  • Reynolds Number
  • External Flow
  • Transient Analysis
  • Turbulence Intensity
  • Solution Adaptive Mesh Refinement
  • Two Dimensional Flow
  • Computational Domain
  • Calculation Control Options
  • Drag Equation
  • Unsteady Vortex Shedding
  • Time Animation
  • Exercise 8: Electronics Cooling
  • Case Study: Heated Cold Plate
  • Conjugate Heat Transfer
  • Real Gases
  • Goals Plot in the Solver Window
  • Exercise 9: Heat Exchanger with Multiple Fluids
  • Case Study: Electronics Enclosure
  • EFD Zooming
  • EFD Zooming – Computational Domain
  • Case Study: Catalytic Converter
  • Porous Media
  • Design Modification
  • Exercise 10: Channel Flow
  • Rotating Reference Frames
  • Part l: Averaging
  • Case Study: Table Fan
  • Noise Prediction
  • Part 2: Sliding Mesh
  • Case Study: Blower Fan
  • Tangential Faces of Rotors
  • Time Step
  • Part 3: Axial Periodicity
  • Exercise 11: Ceiling Fan
  • Case Study: Piston Valve
  • Parametric Analysis
  • Steady State Analysis
  • Parametric Study
  • Part l: Goal Optimization
  • Part 2: Design Scenario
  • Part 3: Multi parameter Optimization
  • Exercise 12: Variable Geometry Dependent Solution
  • Case Study: Dam-Break Flow
  • Free Surface
  • Volume of Fluid (VOF)
  • Experimental Data
  • Exercise 13: Heat Exchanger with Multiple Fluids
  • Case Study: Cone Valve
  • Cavitation
  • Discussion
  • Summary
  • Relative Humidity
  • Case Study: Cook House
  • Problem Description
  • Summary
  • Case Study: Hurricane Generator
  • Particle Trajectories – Overview
  • Particle Study – Physical Settings
  • Particle Study – Wall Condition
  • Exercise 14: Uniform Flow Stream
  • Case Study: Billboard
  • Problem Description
  • Summary
